G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive

    Buy cheap G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive from wholesalers

    Buy cheap G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive from wholesalers
    • Buy cheap G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive from wholesalers
    • Buy cheap G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive from wholesalers

    G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G070VTT01.0
    Price : pls contact us
    Supply Ability : 500
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive

    G070VTT01.0 7 Inch Auo Transparent Display 800×480 4 Wire Resistive

    AUO G070VTT01.0 Optical Details

    Basic Information :
    Luminance
    380 cd/m² (Typ.)
    Contrast Ratio
    500:1 (Typ.) (Transmissive)
    Good View at
    6 o'clock
    Response Speed
    12/18 (Typ.)(Tr/Td) ms
    Viewing Angle
    65/65/50/60 (Typ.)(CR≥10)
    Operating Mode
    TN, Normally White, Transmissive
    Color Performance :
    Chromaticity
    Wx:0.310; Wy:0.340
    Support Color
    262K (6-bit)
    Color Temperature
    6551K
    White Variation
    1.33/1.43 (Typ./Max.)(9 points)
    1931 Color Gamlt :
    NTSC Ratio
    51%
    sRGB
    71% coverage
    Adobe RGB
    54% coverage
    DCI-P3
    53% coverage
    Rec.2020
    38% coverage
    Remarks
    sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.

    AUO G070VTT01.0 Mechanical Details

    Pixel Features :
    Number of Pixel
    800×480(RGB), WVGA
    Arrangement
    RGB Horizontal Stripe
    Dot Pitch(W×H)
    0.1905×0.0635 mm
    Pixel Pitch(W×H)
    0.1905×0.1905 mm [133PPI]
    Physical Size :
    Active Viewing
    152.4(W)×91.44(H) mm
    Overall Dim.
    165(W)×105.8(H) mm
    Bezel Opening
    -
    Overall Depth
    4.51±0.3 mm
    Outline Features :
    Form Shape
    Flat Rectangle
    Orientation
    Landscape type
    Aspect Ratio(W:H)
    15:9
    Shape Style
    Touchscreen :
    TP Controller
    Without touch controller
    TP Interface
    -
    Touch Points
    -
    TP Technology
    4-wire Resistive Touch
    Fixation :
    Without
    Other Detail :
    Mass
    159±15g
    Surface
    Antiglare, Hard coating (3H)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.

    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information

    Panel ModelBrandSize
    X139BLB01.0AUO1.39"
    H381DLN01.0AUO3.8"
    H497TLB01.4AUO5.0"
    H163QLN01.0AUO1.63"
    H139BLN01.2AUO1.39"
    H500TLB01.0AUO5.0"
    X546DLB01.0AUO5.5"
    H546DLB01.1AUO5.5"
    H429ALN01 V0AUO4.3"
    H139BLN01.1AUO1.39"
    M270DTN01.0 CELLAUO27.0"
    T320HVN05.7 CELLAUO31.5"
    T320HVN05.4 CELLAUO31.5"
    T215HVN01.2 CELLAUO21.5"
    B070ATN02.0 CELLAUO7.0"
    M238DAN01.3 CELLAUO23.8"
    B070AAN01.0AUO7.0"
    M238DAN01.1 CELLAUO23.8"
    M270DAN02.0 CELLAUO27.0"
    H598DAN03.0AUO6.0"
    H546TAN02.3AUO5.5"
    G173HW01 V0 CELLAUO17.3"

    FAQ

    1. Q: Where can I get the price?

    A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.

    2. Q: How can I get a sample to check your quality?

    A: After price confirmation, you can require for samples to check our quality.

    3. Q: What about the lead time for mass production?

    A: It depends on your order quantity and the season you place the order.

    4. Q: What are your terms of payment?

    A: We accept T/T, Western Union, MoneyGram, PayPal.


    Shipment for the LCD Display Panels:

    1. Safe & Professional package for our LCD panels.

    2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.

    3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

    4. All our LCD panel will be tested pcs by pcs before been shipped out.
