G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

    Buy cheap G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless from wholesalers

    Buy cheap G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless from wholesalers
    • Buy cheap G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless from wholesalers
    • Buy cheap G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless from wholesalers

    G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G270QAN02.0
    Price : pls contact us
    Payment Terms : Western Union,PAPLY,BANK TRANSFER
    Supply Ability : 500
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless

    G270QAN02.0 AUO 27" LCM 2560×1440 Without Touchscreen And Industrial


    AUO G270QAN02.0 Optical Details

    Basic Detail :
    Luminance
    350 cd/m² (Typ.)
    Contrast Ratio
    1000:1 (Typ.) (Transmissive)
    Good View at
    Symmetry
    Response Speed
    8/8 (Typ.)(Tr/Td) ms
    Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
    Operating Mode
    AHVA, Normally Black, Transmissive
    Color Performance :
    Chromaticity
    Wx:0.313; Wy:0.329
    Support Color
    16.7M (8-bit)
    Color Temperature
    6485K
    White Variation
    1.25/1.33 (Typ./Max.)(9 points)
    1931 Color Gamlt :
    NTSC Ratio
    76%
    sRGB
    100% coverage
    Adobe RGB
    78% coverage
    DCI-P3
    79% coverage
    Rec.2020
    57% coverage
    Remarks
    sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    • G270QAN02.0 AUO LCM Lcd Panel 27 Inch 2560×1440 3 Side Borderless Back to Top

    AUO G270QAN02.0 Mechanical Details

    Pixel Features :
    Number of Pixel
    2560(RGB)×1440, Quad-HD
    Arrangement
    RGB Vertical Stripe
    Dot Pitch(W×H)
    0.0777×0.2331 mm
    Pixel Pitch(W×H)
    0.2331×0.2331 mm [108PPI]
    Physical Size :
    Active Viewing
    596.74(W)×335.66(H) mm
    Overall Dim.
    606.44(W)×355.56(H) mm
    Bezel Opening
    -
    Overall Depth
    10.33/15.03 (Typ./Max.) mm
    Outline Features :
    Form Shape
    Flat Rectangle
    Orientation
    Landscape type
    Aspect Ratio(W:H)
    16:9
    Shape Style
    3-side borderless
    Fixation :
    Rear mounting Pole (14-M3)
    Other Detail :
    Mass
    3.50Kgs (Typ.)
    Surface
    Antiglare, Hard coating (3H)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct

    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information


    Panel ModelBrandSize
    X139BLB01.0AUO1.39"
    H381DLN01.0AUO3.8"
    H497TLB01.4AUO5.0"
    H163QLN01.0AUO1.63"
    H139BLN01.2AUO1.39"
    T320XVN02.F CELLAUO31.5"
    T430HVN01.6 CELLAUO43"
    B101EAN01.2 CELLAUO10.1"
    H497EAN01.0AUO5.0"
    T320XVN02.C CELLAUO31.5"
    T320HVN05.8 CELLAUO31.5"
    T500HVN07.5 CELLAUO50"
    B070EAN02.0 CELLAUO7.0"
    M320QAN01.0 CELLAUO32.0"
    H546TAN02.0AUO5.5"
    H598TAN01.0AUO6.0"

    Packaging & Delivery

    Packaging: Safety Package For all of our LCD Screen Panel Replacements.

    4. Carton Box.


    Details: 1. Antistatic bag

    2. Layers of cartons

    3. Foam Box


    Warranty:

    1. All panels’ grade is promised strictly same as original factory’s standard.

    2. All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.

    3. We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.

    4. ISO 9001 guarantee.
