G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen

    Buy cheap G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen from wholesalers

    Buy cheap G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen from wholesalers
    • Buy cheap G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen from wholesalers
    • Buy cheap G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen from wholesalers

    G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G230HAN01.1
    Price : pls contact us
    Payment Terms : Western Union,PAPLY,BANK TRANSFER
    Supply Ability : 500
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen

    G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen


    G230HAN01.1 AUO 23" LCM 1920×1080 Without Touchscreen And Industrial,Medical Imaging,Gaming


    AUO G230HAN01.1 Mechanical Details

    Pixel Features :
    Pixel Format
    1920(RGB)×1080, FHD
    Dot Pitch
    0.0884×0.2652 mm (H×V)
    Configuration
    RGB Vertical Stripe
    Pixel Pitch
    0.2652×0.2652 mm (H×V) [95PPI]
    Mechanical Size :
    Display Area
    509.184×286.416 mm (H×V)
    Bezel Area
    513.784×291.016 mm (H×V)
    Outline Dim.
    533.2×312 mm (H×V)
    Outline Depth
    10.5±0.5 mm
    Outline Features :
    Form Factor
    Flat Rectangle
    Orientation
    Landscape type
    Aspect Ratio
    16:9 (H:V)
    Shape Style
    Holes & Brackets :
    Side mounting holes (4-M3) on left, right bezel
    Other Features :
    Weight
    1.50±0.15Kgs
    Surface
    Antiglare
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    • G230HAN01.1 AUO 23 Inch Lcd Panel LCM 1920×1080 Without Touchscreen Back to Top

    AUO G230HAN01.1 Optical Details

    Basic Information :
    Brightness
    300 cd/m² (Typ.)
    Contrast Ratio
    1000:1 (Typ.) (Transmissive)
    Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
    Optical Mode
    AHVA, Normally Black, Transmissive
    Viewing Direction
    Symmetry
    Response Time
    8/8 (Typ.)(Tr/Td); 14 (Typ.)(G to G) ms
    Color Performance :
    Chromaticity
    Wx:0.313; Wy:0.329
    Color Numbers
    16.7M (8-bit)
    Color Temperature
    6485K
    Uniformity
    1.25/1.33 (Typ./Max.)(9 points)
    1931 Color Gamlt :
    NTSC Ratio
    71%
    sRGB
    97% coverage
    Adobe RGB
    74% coverage
    DCI-P3
    74% coverage
    Rec.2020
    53% coverage
    Remarks
    sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
