    a - Si lcd tft monitor AT070TN93 7.0 inch 164.9×100×7 mm Outline

    Ask Lasest Price
    Brand Name : Innolux LCD Panel
    Model Number : AT070TN93
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    a - Si lcd tft monitor AT070TN93 7.0 inch 164.9×100×7 mm Outline

    a-Si TFT-LCD , Panel AT070TN93 7.0 inch 800(RGB)×480 , WVGA Resolution 164.9×100×7 mm Outline

    INNOLUX AT070TN93 General Features:

    Panel Brand :INNOLUX
    Panel Model :AT070TN93
    Panel Type :a-Si TFT-LCD , Panel
    Panel Size :7.0 inch
    Resolution :800(RGB)×480 , WVGA
    Display Mode :TN, Normally White, Transmissive
    Active Area :154.08×85.92 mm
    Outline :164.9×100×7 mm
    Surface :Antiglare
    Brightness :320 cd/m² (Typ.)
    Contrast Ratio :500:1 (Typ.)
    Display Colors :262K/16.7M (6-bit / 6-bit + Dithering)
    Response Time :10/15 (Typ.)(Tr/Td)


    Our Advantages:


    Q1: Can I place sample order first?
    A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
    Q2: How could I pay them?
    A2: PayPal, Western Union and T/T are preferred, so just tell us which is easier to you. Then we will send you our bank details. Or your requirements.
    Q3: How to place the order?
    A3: Please send us your purchase order by e-mail, Trade Manager or Skype or you can ask us to send you a Proforma Invoice for your order.
    Q4: How long can I get my order?
    A4: For samples, we will finish production and ship within 7~10 working days. For bulk orders, usually 15~20 working days and depends on your design.
    Q5: How to send us the products?
    A5: We usually use DHL, UPS, FedEx to ship samples. For bulk orders, we support shipping by air or by sea.
    Q6: Can you customize according to our designs and put our logo on the products?
    A6: Yes, we support both standard and customized products and can put your logo on the products. Our experienced R&D team will support technical questions. ODM/OEM is welcome.

    INNOLUX AT070TN93 Signal Interface:


    Signal Category :TTL
    Signal Class :Parallel RGB (1 ch, 6/8-bit)
    Input Voltage for Panel :3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
    Input Current for Panel :4.0/20.0/0.2/0.2mA (Typ.)(ICC/IAVDD/IGH/IGL)
    Panel Power Consumption :226mW (Typ.)
    Voltage for Display Signals :0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD
    Interface Type :FPC
    Signal Interface :BrandModelPin PitchPinsAmountConfiguration
    0.5 mm50 pins1 pcsDRGB-50P1C8B-115A

    Packing & Delivery for our LCD Screen Panel Replacements


    1. Anti-static Bag Packing.
    2. Anti-Shock Bubble Bag Packing.
    3. Foam and Hard Carton Packing.
    4. Picked up by forward and delivered by express services.


    Company Strength:


    1. ISO9001 certificated, Factory Direct Supplied.

    2. Competitive Price and Short Lead-time.

    3. Professional Team with Rich Experiences in Design / Mfg / Quality Control.

    4. Small MOQ Support & Fast Response to Customers.

    5. Long Porduct Life Time.


    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information: salespm@nselectronic.com.hk

    Panel ModelBrandSizeResolution
    V156B2-P02Innolux15.6"1366×768
    N154I2-P05Innolux15.4"1280×800
    C03024-01ZInnolux3.0"960×480(dot)
    G121IJ1-P01Innolux12.1"1280×800
    F04307-06ZInnolux4.3"480×800
    CG043JN16Innolux4.3"480×800
    F04008-01UInnolux4.0"480×800

    Details Pictures for AT070TN93:
    a - Si lcd tft monitor AT070TN93 7.0 inch 164.9×100×7 mm Outline


    a - Si lcd tft monitor AT070TN93 7.0 inch 164.9×100×7 mm Outline
