    5.0 inch 40PIN HD TFT LCD Screen(16:9) TM050QDH03 800*480

    Ask Lasest Price
    Brand Name : Tianma LCD Displays
    Model Number : TM050QDH03
    Certification : ISO9001
    Payment Terms : T/T, Paypal, Western Union, MoneyGram
    Supply Ability : 100 PCS / DAY
    Delivery Time : 2-3 working days after payment confirmation
    • Product Details
    • Company Profile

    5.0 inch 40PIN HD TFT LCD Screen(16:9) TM050QDH03 800*480

    Original Pegasus 7 inch high screen 1280*800 TM070JDHP01 SIP Normally Black


    Overview of Production :


    <







    TIANMA TM050QDH03 Mechanical Features








    Panel Size :5.0 inch
    Dot Resolution :640(RGB)×480 (VGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :160 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0529×0.1587 mm (H×V)
    Pixel Pitch :0.1587×0.1587 mm (H×V)
    Weight :86±4.3g
    Surface :Antiglare, Hard coating (3H)
    Active Area :101.568×76.176 mm (H×V)
    Outline Dimension :113.6×88.4 mm (H×V)
    Outline Depth :8.1/10.0 (Typ./Max.) mm
    Holes & Brackets :Face mounting holes (4 pcs) on left, right slugs
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    TIANMA TM050QDH03 Electronics Feature

    Vertical Frequency :60Hz
    Reverse Scan :No
    Driver IC :Built-in NT39403B + NT39207
    Time Controller (T-CON) :Embedded T-CON





    TIANMA TM050QDH03 Backlight System



    Lamp Position :Edge light type
    Lamp Type :WLED
    Lamp Amount :3S5P
    Lamp Shape :Array
    Lamp Life Time :50K(Typ.) (Hours)
    Interface Type :Included in panel signal interface
    Lamp Driver Board :Embedded (LED Driver)
    Lamp Driver Board :5.0±0.5V
    Lamp Driver Board :240mA (Typ.)
    Lamp Driver Board :1.2W (Typ.)

    Accept batch order, Please contact us via mail or trademanager


    Factory direct offers with professional factory support

    1. We will double QC test before shipping

    2. Focus on 100% customer satisfaction


    Trade Terms:


    1. Payment terms: 100% by T/T when order confirmed

    2. Lead time: 2-5 working days according to the order quantity

    3. Sample lead time: within 3 working days after we get payment.

    4. The price based on FOB Shenzhen,we will offer best discount according to order quantity.

    5. Warranty:offer free spare parts within ONE year.

    6. Offer OEM service for batch orders,to print logo and design box.


    More Information For N&S electronic Co.,LTD:


    We have a good reputation in the trading of electronic components and have built up a wide and stable relationship with agency and distributors of electronic components.


    Our products have won praise from customers worldwide. We not only offer our own stock, but also help clients to search the parts in Chinese market.


    We have implemented a strict and complete quality control system which ensures that all parts we offer are of good quality.


    We have experienced workers and professional equipment to inspect the parts before shipment and always inform clients the true conditions of the parts.


    We would appreciate the opportunity of serving your component needs. You will be pleased to do business with us for our best services and high quality components.
    Please contact us by fax, phone or email, so we can quote you the best price as per your requirements.


    Our aim is to help customers realize their goals. We are making great efforts to achieve this win-win situation and sincerely welcome you to join us.


    Pictures of TIANMA TM050QDH03 LCD Display:


    5.0 inch 40PIN HD TFT LCD Screen(16:9) TM050QDH03 800*4805.0 inch 40PIN HD TFT LCD Screen(16:9) TM050QDH03 800*4805.0 inch 40PIN HD TFT LCD Screen(16:9) TM050QDH03 800*480
