Antiglare 18.5" Chimei LCD Panel With Dot Matrix Lcd Display G185BGE-L01

CHIMEI INNOLUX G185BGE-L01 General Features :

Panel Model : G185BGE-L01
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 18.5 inch
Resolution : 1366(RGB)×768 , WXGA
Display Mode : TN, Normally White, Transmissive
Active Area : 409.8×230.4 mm
Outline : 430.37×254.6×16.6 mm
Surface : Antiglare (Haze 25%), Hard coating (3H)
Brightness : 300 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 72%
Response Time : 1.5/3.5 (Typ.)(Tr/Td)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED Embedded (LED Driver)
Signal Interface : LVDS (1 ch, 8-bit) , 30 pins
Input Voltage : 5.0V (Typ.)

For delivery

Note: The LCD screens are precious and fragile, especially the Car Monitor LCD, If you are in
Urgent need, or the LCD is very important to you, Please choose the DHL express. Because China Post:
A. Damage goods easily
B. Spend very long time, sometimes more than 1 month
C. No security
D. Lost goods easily
E. Prone to accidents
F. If it has any problems about the shipping, we will not take any responsibility.

Payment Way:

1. For Retail: Paypal / Escrow / Western Union
2. For Large QTY: T/T bank transfer / Escrow / Paypal

For Replacement Rule :

1. LCD is a kind of fragile product, they are all 100% tested and safely packed by our staffs, but
It will have little possibility of broken condition when delivery, so please make sure to open
The package when receiving product from shipping company, if the product is broken, please
Ask shipping company staff to provide a file of broken certification, and deliver it back to us,
We will do the replacement ASAP. If the broken LCD is without certification from shipping
Company, then our company is irresponsible for it.

CHIMEI INNOLUX G185BGE-L01 Optical Features :

<

Picture for CHIMEI INNOLUX G185BGE-L01 :

Who we are:

      N&S ELECTRONIC CO., LTD established in year 2010. Our headquarters located in Hong Kong and branch office in Shenzhen, Singapore, Malaysia and Canada. We are professional distributor on LCD panels with our own warehouse and stock. Our goal is to provide worldwide supply chain solution based on integrity.

What we do:

      As the leading LCD distributor in China, we are strong at EOL panels and hard to find panels of famous brands such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE etc.

     Our products lines are widely used on medical apparatus, industrial control facilities, portable electrical impedance measurement apparatus, digital video camera display, vehicle equipment, aerospace equipment.

     Our products mostly cover small sizes, like 1.5", 2.0", 2.2", 2.5", 3.0", 3.5", 4.0", 4.2", 4.3", 4.7", 5.0", 5.5", 5.7", 6.0", 6.4", 7.0", 8.0", 10.1", 10.4", 12.1", etc. Most of them are original factory sealed carton packing. Moreover, we will do the brightness inspection of them by testing board.

Our Advantages:

       LCD panels are sourced directly from manufacturers, OEM/CM's and worldwide business partners spanning five continents that include 40 COUNTRIES or AREAS, United States, Italy, Singapore, Korea, Taiwan, Germany, Thailand, Malaysia, Japan, etc. There are more than 540 enterprises. With our strong sourcing team and sufficient stock in our warehouse, and our professional Quality Control team and professional testing instruments, we can offer reliable quality panels at competitive price.

     N&S will be your powerful partner on LCDs in China. Here we are to quote your need.
