    BOE 10.1 inch ADS Normally Black Screen BP101WX1-100 SVGA 1280(RGB)×800 TFT LCD Module

    Ask Lasest Price
    Brand Name : BOE
    Model Number : BP101WX1-100
    Certification : ISO9001
    Price : USD
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-2days
    • Product Details
    • Company Profile

    BOE 10.1 inch ADS Normally Black Screen BP101WX1-100 SVGA 1280(RGB)×800 TFT LCD Module

    BOE 10.1 inch ADS Normally Black Screen BP101WX1-100 SVGA 1280(RGB)×800 TFT LCD Module

    BOE BP101WX1-100 Features :

    <

    Panel Brand :BOE
    Panel Model :BP101WX1-100
    Panel Type :a-Si TFT-LCD , Panel
    Panel Size :10.1 inch
    Resolution :1280(RGB)×800 , WXGA
    Display Mode :ADS, Normally Black, Transmissive
    Active Area :216.96×135.6 mm
    Outline :227.56×148.2 mm
    Surface :Hard coating (3H), Antireflection
    Brightness :450 cd/m² (Typ.)
    Contrast Ratio :800:1 (Typ.)
    Display Colors :16.7M (6-bit + Hi-FRC) , CIE1931 50%
    Response Time :24 (Typ.)(Tr+Td)
    Viewing Angle :85/85/85/85 (Typ.)(CR≥20) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :7S6P WLED Without Driver
    Signal Interface :LVDS (1 ch, 8-bit) , 40 pins
    Input Voltage :3.3V (Typ.)


    Company Information:


    ShenZhen N&S Technology CO., LTD was established in 2010, Speciliazed in the LCD product development / production, we holds the operating philosophy of "quality, service, responsibility, innovation".

    Our products have passed the certification of ISO9001 Quality Management System in order to improve quality of our products.

    We have a wealth of professional experience and strong research and development, always walk in the forefront of the industry in the fierce market competition, with unremitting efforts to achieve development!

    Our Advantages for LCD panel:


    1FOG automatical device can ensure the capacity of 1000,000 per month.
    2MOQ can be 100pcs, lead time of standard products is 20 days.
    3Reliability test and full examination to ensure the high quality of the display.
    4OEM&ODM are provided for TFT/TN LCD/Plastic Moulding.
    5Strictly ISO quality management system.
    6Mature and Professional R&D and after service.
    7Various cooperation experience with big brands

    Some Pictures about BOE BP101WX1-100 :



    BOE 10.1 inch ADS Normally Black Screen BP101WX1-100 SVGA 1280(RGB)×800 TFT LCD ModuleBOE 10.1 inch ADS Normally Black Screen BP101WX1-100 SVGA 1280(RGB)×800 TFT LCD Module
