PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare

    Buy cheap PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare from wholesalers

    Buy cheap PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare from wholesalers
    • Buy cheap PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare from wholesalers
    • Buy cheap PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare from wholesalers

    PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare

    Ask Lasest Price
    Brand Name : PVI
    Model Number : PD035VX2
    Certification : ISO9001
    Payment Terms : T/T, Western Union, Paypal, MoneyGram
    Supply Ability : 100 PCS Per Day
    Delivery Time : 2-3 Working Days after Order Confirmation
    • Product Details
    • Company Profile

    PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare

    PVI 3.5 Inch Industrial LCD Displays PD035VX2 With 262K Antiglare


    Main features:


    Panel Brand :PVI
    Panel Model :PD035VX2
    Panel Type :a-Si TFT-LCD , Panel
    Panel Size :3.5 inch
    Resolution :640(RGB)×480 , VGA
    Display Mode :TN, Normally White, Transmissive
    Active Area :72×52.56 mm
    Outline :84.03×65.24 mm
    Surface :Antiglare
    Brightness :450 cd/m² (Typ.)
    Contrast Ratio :600:1 (Typ.)
    Display Colors :262K (6-bit)
    Response Time :15/25 (Typ.)(Tr/Td)
    Viewing Angle :75/75/50/60 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :3S2P WLED Without Driver
    Signal Interface :TTL (1 ch, 6-bit) , 50 pins
    Input Voltage :3.3/3.3/10/17/-10V (Typ.)(VCC/VDD/VDD1/VCG/VEE)

    Technical Specifications for PVI PA064DS1 LCD Panel:

    <

    Display Mode :TN, Normally White, Transmissive
    Brightness :450 cd/m² (Typ.)
    Contrast Ratio :600 : 1 (Typ.) (Transmissive)
    Display Color :262K (6-bit)
    Response Time :15/25 (Typ.)(Tr/Td)
    Viewing Angle :75/75/50/60 (Typ.)(CR≥10) (L/R/U/D)
    White color Chromaticity :Wx:0.310; Wy:0.330
    White Variation :1.33/1.43 (Typ./Max.)(9 points)

    The above parameters are inputted by electronic engineers according to the datasheet, every effort has been made to reduce errors, but we can not guarantee that the parameter is entirely correct.

    <

    Our company advantage in the TFT LCD Display Panel area:


    As one of the leading LCD distributor in China, we are strong at EOL panels and hard to find shortage panels of world famous Brand such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA HITACHI/KOE Etc.

    We work closely with more than 540 enterprises in the world, including large OEM factories,franchised distributors and well-known independent distributors in LCD industry.


    PVI PA064DS1 Electronics Feature:

    Vertical Frequency :60Hz
    Reverse Scan :Yes (U/D, L/R)
    Total Power Consumption :564/788mW (Typ./Max.)
    Time Controller (T-CON) :Need external T-CON: PVI-2002A or PVI-2003A
