NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.)

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.) from wholesalers

    Buy cheap NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.) from wholesalers
    • Buy cheap NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.) from wholesalers

    NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.)

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : NT156WHM-N32
    Certification : ISO9001
    Payment Terms : Western Union, T/T, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.)

    NT156WHM-N32 15.6inch 1366×768 Resolution 344.232×193.536 mm Active Area Contrast Ratio 500:1 (Typ.)


    NT156WHM-N32 Basic Information

    Panel ModelNT156WHM-N32
    Panel BrandBOE
    Descritiona-Si TFT-LCD ,15.6 inch, 1366×768
    Panel Typea-Si TFT-LCD
    Operating Temperature0 ~ 50 °C
    Storage Temperature-20 ~ 60 °C
    RemarkseDP1.2

    NT156WHM-N32 Mechanical Features

    Dot Resolution1366(RGB)×768 (WXGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density100 PPI
    Aspect Ratio16:9 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.084×0.252 mm (H×V)
    Pixel Pitch0.252×0.252 mm (H×V)
    Weight370g (Max.)
    SurfaceGlare (Haze 0%)
    Active Area344.232×193.536 mm (H×V)
    Outline Dimension359.5×223.8 mm (H×V)
    Outline Depth3.8 (Max.) mm
    Shape StyleFlat (PCBA Flat, Depth 3.4~4.0mm)
    Holes & BracketsFace mounting holes (8 pcs) on up, down slugs
    Landscape or PortraitLandscape type
    Touch PanelWithout

    We Can Do for You:

    1) One-to-one service with efficient & professional support;

    2) Protection of your design and all your private information;

    3) We could supply different hard disk for you.

    4) Quality stability, can to provide certification of products;

    5) Convenient payment methods: PayPal, T/T and Western Union;

    6) Speedy shipment: we could arrange the shipment within 1-3 business days.

    7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.

    8) Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the savings to you.


    Competitive Advantage:

    1. Rich experience.
    Having been specialized in this field for years, we have rich experience and widespread sales network around the word.

    2. Great quality and high purity
    Good quality is one secret for our success.

    3. Safest and fastest delivery.
    We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
    4. Good after-sales service.
    24/7 is available. Try our best to solve various problems customers encountered!


    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    BV043WVL-N50-1Q00BOE4.3"480×800
    BV050SQE-N42-3Q00BOE5.0"540×960
    HV550FHB-N20BOE55"1920×1080
    BS055FHG-E41-6900BOE5.5"1080×1920
    BS055FHG-N41-6901BOE5.5"1080×1920
    BS050FHE-E40-6Q00BOE5.0"1080×1920
    AV074ZAB-NW0BOE7.4"1280×400
    HV550QUB-B11BOE55"3840×2160
    BV050FWE-N41BOE5.0"480×854
    DV230FHD-NT0BOE23.0"1920×1080
    BA070WS2-102BOE7.0"1024×600
