    TFT LCD Module TM150TDSG52 15.0 inch Active Area 304.128×228.096 mm resolution 1024×768 Normally White

    Ask Lasest Price
    Brand Name : AVIC
    Model Number : TM150TDSG52
    Certification : ISO9001
    Payment Terms : Western Union, T/T, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    TFT LCD Module TM150TDSG52 15.0 inch Active Area 304.128×228.096 mm resolution 1024×768 Normally White

    TFT LCD Module TM150TDSG52 15.0 inch Active Area 304.128×228.096 mm resolution 1024×768 Normally White


    Packaging & Delivery
    Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.
    Delivery Detail: 2-3 days after receipt of payment
    Payment terms: We accept T/T, PayPal, Western Union and others.


    TM150TDSG52 Basic Information

    Panel ModelTM150TDSG52
    Panel BrandAVIC
    Descritiona-Si TFT-LCD ,15.0 inch, 1024×768
    Panel Typea-Si TFT-LCD
    Operating Temperature0 ~ 65 °C
    Storage Temperature-20 ~ 65 °C

    TM150TDSG52 Mechanical Features

    Dot Resolution1024(RGB)×768 (XGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density85 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.099×0.297 mm (H×V)
    Pixel Pitch0.297×0.297 mm (H×V)
    Weight1.00Kgs (Typ.)
    SurfaceAntiglare
    Active Area304.128×228.096 mm (H×V)
    Bezel Area307.4×231.3 mm (H×V)
    Outline Dimension326.5×253.5 mm (H×V)
    Outline Depth11.8±0.3 mm
    Holes & BracketsSide mounting holes (4-M3) on left, right bezel
    Landscape or PortraitLandscape type
    Touch PanelWithout

    TM150TDSG52 Optical Features

    Display ModeTN, Normally White, Transmissive
    Brightness250 cd/m² (Typ.)
    Contrast Ratio600 : 1 (Typ.) (Transmissive)
    Display Color262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Color Gamut60% NTSC (CIE1931)
    Response Time3/5 (Typ.)(Tr/Td)
    Viewing Angle80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
    White color ChromaticityWx:0.313; Wy:0.329
    White Variation1.25/1.33 (Typ./Max.)(9 points)
    Sunlight ReadableN

    Competitive Advantage:
    1. We are a leading vendor & distributor for the LCD panels for more than 6 years.
    2. We got the ISO9001 quality management system certification.
    3. We have our own sourcing line & agency for the hard-to-find & shortage LCD panel models.
    4. We are the professional team for the LCD screen sourcing & international trade with 6-year experience.
    5. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 1-3 working days.
    6. 1-year warranty is offered.
    7. All LCD Panel will be tested before shipment.
    8. We are the vendor & distributor in LCD panel area already for 6 years. We own our professional & competitive LCD screen sourcing line.

    Here comes our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    TV070WSU-N40BOE7.0"600×1024
    LS320PUWTHPANDA31.5"1366×768
    TT4851D01-4CSOT49"3840×2160
    ST4761B01-6CSOT48"1920×1080
    LC420EGY-SGM1LG Display42"3840×2160
    H466TAN01.4AUO4.7"720×1280
    BF045WVE-400BOE4.5"480×854
    LC430DUY-SHA1LG Display43"1920×1080
    HSD047BMW1-D00HannStar4.7"540×960
    HSD070FMW1-A00HannStar7.0"540×960
