New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch

    Buy cheap New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch from wholesalers

    Buy cheap New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch from wholesalers
    • Buy cheap New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch from wholesalers
    • Buy cheap New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch from wholesalers

    New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch

    Ask Lasest Price
    Brand Name : NAN YA
    Model Number : LTBSHT702G21CKS
    Certification : ISO9001
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    New / Original Medical LCD Displays LTBSHT702G21CKS NAN YA FSTN-LCD 9.4 Inch

    New and original LTBSHT702G21CKS NAN YA FSTN-LCD ,9.4 inch, 640×480 for 60Hz


    LTBSHT702G21CKS Basic Information

    Panel ModelLTBSHT702G21CKS
    Panel BrandNAN YA
    DescritionFSTN-LCD ,9.4 inch, 640×480
    Panel TypeFSTN-LCD
    Operating Temperature-20 ~ 70 °C
    Storage Temperature-30 ~ 80 °C

    Packaging & Delivery

    Packaging Details:

    Antistatic bag + Bubble bag + Foam box + Carton box

    Delivery Detail:

    1-3 working days after payment confirmed

    LTBSHT702G21CKS Mechanical Features

    Dot Resolution640×480 (VGA)
    Pixel ConfigurationRectangle
    Pixel Density84 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.300×0.300 mm (H×V)
    Pixel Pitch0.300×0.300 mm (H×V)
    Weight350g
    SurfaceAntiglare
    Active Area191.97×143.97 mm (H×V)
    Bezel Area202.4×151.2 mm (H×V)
    Outline Dimension260.5×174 mm (H×V)
    Outline Depth7.3/8.0 (Typ./Max.) mm
    Holes & BracketsFace mounting holes (4-Φ3.5)
    Landscape or PortraitLandscape type
    Touch PanelWithout

    Quality Control:

    1. Visual Inspection

    Make sure No damage, No Scratches, No dusty, No light leakage.

    1. Function Inspection

    Make sure all functions are 100% tested ok

    LTBSHT702G21CKS Optical Features

    Display ModeSTN, Black/White (Negative), Transmissive
    Brightness70 cd/m² (Typ.)
    Contrast Ratio20 : 1 (Typ.) (Transmissive)
    Display ColorMonochrome ()
    Response Time300/200 (Typ.)(Tr/Td)
    Viewing Direction6 o'clock
    Sunlight ReadableN

    Packing& Shipping:
    Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
    Guarantee:
    (1) All items will be strictly tested and shipped with strong package.
    (2) We have 3~6months warranty for every item, depend on the different item.
    (3) We will do our best to solve any possible problem for your after sale. Please contact with us.

    LTBSHT702G21CKS Electronics Feature

    Vertical Frequency70Hz
    Reverse ScanNo

    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    LCBKET302M2CNAN YA7.5"640×480
    LCBHBT161MNAN YA5.7"320×240
    LCBLDT163M14CNAN YA7.4"640×480
    LCBLDT163M2SNAN YA7.4"640×480
    LCBLDT163MCNAN YA7.4"640×480
    LKCEAZ740YKSNAN YA5.7"320×240
    LTBSHT702G21CKSNAN YA9.4"640×480
    LMCJ6S003J17CDPNAN YA5.2"240×64

    We also have other industrial LCD panels, pls contact to us for the further information


    LTBSHT702G21CKS pictures
