    LQ150X1DG11 SHARP 15.0 inch TN, Normally White, Transmissive Outline 331.3×257.9 mm Frequency 60Hz

    Ask Lasest Price
    Brand Name : SHARP
    Model Number : LQ150X1DG11
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    LQ150X1DG11 SHARP 15.0 inch TN, Normally White, Transmissive Outline 331.3×257.9 mm Frequency 60Hz

    LQ150X1DG11 SHARP 15.0 inch TN, Normally White, Transmissive Outline 331.3×257.9 mm Frequency 60Hz

    LQ150X1DG11 Basic Information

    Panel ModelLQ150X1DG11
    Panel BrandSHARP
    Descritiona-Si TFT-LCD ,15.0 inch, 1024×768
    Panel Typea-Si TFT-LCD
    Operating Temperature0 ~ 50 °C
    Storage Temperature-25 ~ 60 °C

    LQ150X1DG11 Mechanical Features

    Dot Resolution1024(RGB)×768 (XGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density85 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.099×0.297 mm (H×V)
    Pixel Pitch0.297×0.297 mm (H×V)
    Weight1.30Kgs (Max.)
    SurfaceAntiglare (Haze 28%), Hard coating (2H)
    Active Area304.1×228.1 mm (H×V)
    Bezel Area308.2×232.1 mm (H×V)
    Outline Dimension331.3×257.9 mm (H×V)
    Outline Depth15.9 (Typ.) mm
    Holes & BracketsSide mounting holes (8-M2.5) on left, right bezel
    Landscape or PortraitLandscape type
    Touch PanelWithout


    Packaging & Delivery
    Packaging Details:
    Safey package
    Plastic trays inside
    2 layes of cartons
    Fragile sign on top
    Can be customize 3.5 inch spare parts auo used lcd panel
    Delivery Detail: 1-3 Working Days

    Why do you choose us?
    • Quick response to clients' enquiries within 24hrs.
    • More than 6-year experience in LCD screen field and professional team communication team.
    •Value quality and long-term cooperation to reach win-win relationship.

    LQ150X1DG11 Optical Features

    Display ModeTN, Normally White, Transmissive
    Brightness200 cd/m² (Typ.)
    Contrast Ratio300 : 1 (Typ.) (Transmissive)
    Display Color262K (6-bit)
    Response Time10/35 (Typ.)(Tr/Td)
    Viewing Angle70/70/60/60 (Typ.)(CR≥10) (L/R/U/D)
    White color ChromaticityWx:0.313; Wy:0.329
    White Variation1.35 (Max.)(5 points)
    Sunlight ReadableN

    Here comes our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    LK315T3HC1KSHARP31.5"1366×768
    LQ055T3SX04SHARP5.5"1080×1920
    LQ079L1SX06SHARP7.9"1536×2048
    LQ079L1SX04SHARP7.9"1536×2048
    LQ133M1JW08SHARP13.3"1920×1080
    LQ156D1JX02SHARP15.6"3840×2160
    LQ156Z1JW01SHARP15.6"3200×1800
    LQ133T1JW14BSHARP13.3"2560×1440
    LQ047K3SX04SHARP4.7"720×1280
    LS024Q8UC92SHARP2.4"240×320
