R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz

    Buy cheap R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz from wholesalers

    Buy cheap R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz from wholesalers
    • Buy cheap R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz from wholesalers
    • Buy cheap R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz from wholesalers
    • Buy cheap R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz from wholesalers

    R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz

    Ask Lasest Price
    Brand Name : INNOLUX
    Model Number : R190EFE-L61
    Certification : ISO9001
    Price :
    Payment Terms :
    Supply Ability :
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz

    R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz


    R190EFE-L61 Basic Information

    Panel ModelR190EFE-L61
    Panel BrandINNOLUX
    Descritiona-Si TFT-LCD ,19.0 inch, 1280×1024
    Panel Typea-Si TFT-LCD
    Operating Temperature0 ~ 50 °C
    Storage Temperature-20 ~ 60 °C

    Shipment for the LCD Display Panels:

    1. Safe & Professional package for our LCD panels.

    2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.

    3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

    4. All our LCD panel will be tested pcs by pcs before been shipped out.

    R190EFE-L61 Mechanical Features

    Dot Resolution1280(RGB)×1024 (SXGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density86 PPI
    Aspect Ratio5:4 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.098×0.294 mm (H×V)
    Pixel Pitch0.294×0.294 mm (H×V)
    Weight1.87/2.07Kgs (Typ./Max.)
    SurfaceAntiglare, Hard coating (3H)
    Active Area376.32×301.06 mm (H×V)
    Bezel Area380.3×305.0 mm (H×V)
    Outline Dimension396×324 mm (H×V)
    Outline Depth19.8/20.7 (Typ./Max.) mm
    Holes & BracketsSide mounting holes (4 pcs) on left right bezel
    Landscape or PortraitLandscape type
    Touch PanelWithout

    Quality Control:

    1. Visual Inspection

    Make sure No damage, No Scratches, No dusty, No light leakage.

    1. Function Inspection

    Make sure all functions are 100% tested ok


    R190EFE-L61 Optical Features

    Display ModeDD-IPS, Normally Black, Transmissive
    Brightness650 cd/m² (Typ.)
    Contrast Ratio900 : 1 (Typ.) (Transmissive)
    Display Color16.7M (8-bit)
    Color Gamut72% NTSC (CIE1931)
    Response Time15/15 (Typ.)(Tr/Td)
    Viewing Angle85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
    Viewing DirectionSymmetry
    White color ChromaticityWx:0.313; Wy:0.329
    Sunlight ReadableN

    Packing& Shipping:
    Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
    Guarantee:
    (1) All items will be strictly tested and shipped with strong package.
    (2) We have 3~6months warranty for every item, depend on the different item.
    (3) We will do our best to solve any possible problem for your after sale. Please contact with us.

    R190EFE-L61 Electronics Feature

    Vertical Frequency60Hz
    Reverse ScanNo
    Total Power Consumption26W (Typ.)

    Below are our other LCD panels stock for your easy reference:


    Panel ModelBrandSizeResolution
    EE080NA-06AInnolux8.0"800×600
    AT080TN60Innolux8.0"800×480
    EE070NA-01LInnolux7.0"1024×600
    EE070NA-01DInnolux7.0"1024×600
    AT070TN90 V.1Innolux7.0"800×480
    AT070TN00 V.1Innolux7.0"480×234
    AT050TN30Innolux5.0"480×272
    LW700AT6005Innolux7.0"800×480

    We also have other industrial LCD panels, pls contact to us for the further information


    R190EFE-L61 pictures


    Quality R190EFE-L61 INNOLUX a-Si TFT-LCD ,19.0 inch, 1280×1024 for 60Hz for sale
