12.1 Inch 1024×768 Medical Grade LCD Monitors T-55105D121J-FW-A-AAN OPTREX

Ask Lasest Price
Brand Name :	OPTREX
Model Number :	T-55105D121J-FW-A-AAN
Certification :	ISO9001
Price :
Payment Terms :
Supply Ability :
Delivery Time :	1-3 Working Days

Add to Cart

Product Details
Company Profile

12.1 Inch 1024×768 Medical Grade LCD Monitors T-55105D121J-FW-A-AAN OPTREX

T-55105D121J-FW-A-AAN OPTREX a-Si TFT-LCD ,12.1 inch, 1024×768 for Industrial Application

T-55105D121J-FW-A-AAN Basic Information

Panel Model	T-55105D121J-FW-A-AAN
Panel Brand	OPTREX
Descrition	a-Si TFT-LCD ,12.1 inch, 1024×768
Panel Type	a-Si TFT-LCD
Model Alias	AA121XJ01
Operating Temperature	-20 ~ 70 °C
Storage Temperature	-20 ~ 80 °C
Remarks	NCM

Why do you choose us?
• Quick response to clients' enquiries within 24hrs.
• More than 6-year experience in LCD screen field and professional team communication team.
•Value quality and long-term cooperation to reach win-win relationship.

T-55105D121J-FW-A-AAN Mechanical Features

Dot Resolution	1024(RGB)×768 (XGA)
Pixel Configuration	RGB Vertical Stripe
Pixel Density	105 PPI
Aspect Ratio	4:3 (H:V)
Form Factor	Flat Rectangle Display
Dot Pitch	0.080×0.240 mm (H×V)
Pixel Pitch	0.240×0.240 mm (H×V)
Weight	1.15Kgs (Typ.)
Surface	Antiglare, Hard coating (3H)
Active Area	245.76×184.32 mm (H×V)
Bezel Area	249.0×187.5 mm (H×V)
Outline Dimension	280×219 mm (H×V)
Outline Depth	17.8 (Typ.) mm
Holes & Brackets	Face mounting holes (4-Φ3.5) on left, right bezel
Landscape or Portrait	Landscape type
Touch Panel	Without

Our services
1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4.Apart from the Indoor LED Display, Visionled also can offer you LED Pharmacy Cross Display, LED Flexible Display, Outdoor LED Display, LED Gas Price Signs, Indoor/outdoor LED Signs.

T-55105D121J-FW-A-AAN Optical Features

Display Mode	TN, Normally White, Transmissive
Brightness	1000 cd/m² (Typ.)
Contrast Ratio	600 : 1 (Typ.) (Transmissive)
Display Color	262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Gamut	40% NTSC (CIE1931)
Response Time	6/19 (Typ.)(Tr/Td)
Viewing Angle	65/65/45/75 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction	6 o'clock
White color Chromaticity	Wx:0.313; Wy:0.329
White Variation	1.30 (Max.)(5 points)
Sunlight Readable	Y

We can do for You:

Quality Guarantee:

100% original new Hard Disk for you.
2．Fast reply:
Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.
3．Delivery Guarantee:
Large Stock System, We have our own warehouses in Shenzhen and Hong Kong, with comprehensive supply lines.
4．After-Sale Service:
Professional support team to provide effective service, we are young and full of passion!
5. Professional acknowledgement of hard disks to provide customers with effective advice.
We have been in hard disk business for more than 6 years and know the main brands' hard disk very well.
6. Competitive quotation:
Our big customer network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

T-55105D121J-FW-A-AAN Electronics Feature

Vertical Frequency	60Hz
Reverse Scan	Yes (180°)
Total Power Consumption	15.0W (Typ.)

Below are our other LCD panels stock for your easy reference:

Panel Model	Brand	Size	Resolution
DMF5010NF-FW-BE	Kyocera	5.2"	240×64
DMF5010NF-FW	Kyocera	5.2"	240×64
DMF5010NBU-FW-BD	Kyocera	5.2"	240×64
DMF5010NBU-FW	Kyocera	5.2"	240×64
DMF5010NB-FW-BC	Kyocera	5.2"	240×64
DMF5010NB-FW	Kyocera	5.2"	240×64
KCS6448BSTT-X15	Kyocera	10.4"	640×480
DMF-5001NY-LY-ATE-BBN	Kyocera	4.7"	160×128

We also have other industrial LCD panels, pls contact to us for the further information

T-55105D121J-FW-A-AAN pictures
