TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area from wholesalers

    Buy cheap TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area from wholesalers
    • Buy cheap TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area from wholesalers

    TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area

    Ask Lasest Price
    Brand Name : Tianma
    Model Number : TM101JDHP01
    Certification : ISO9001
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 2-3 Working Days after order confirmation
    • Product Details
    • Company Profile

    TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area


    TM101JDHP01 Tianma Industrial Flat Panel Display Panel with 216.96×135.6 mm Active Area


    Excellent service on before-sale, on-sale and after-sale

    1. We provide one year warranty, will provide the after-sale service for you if any quality problems.

    2.Your inquiry related to our products or prices will be replied in 24 hours.

    3. We will track the shipping status time by time so that buyer can receive our goods in time and safely.


    Our Service

    1. Small quantity also can be provided.

    2. New models can be updated fast.
    3. We have strict QC team to make sure all products are qualified before delivery.
    4. Warranty promise

    5. Sourcing line for different hard disks for different brands.


    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    TM060SDH01Tianma6.0"800×600
    TM128128A4KFWGWC69-1Tianma1.5"128×128
    TM12864LCAWGTianma2.2"128×64
    TM9616AGHWGNATianma0.84"96×16
    TM128160LKFWG5-1Tianma1.8"128×160
    TM320240EGFWVSWDTianma5.7"320×240
    TM320240ECCWVSWDTianma5.7"320×240
    TM240128ABCWVBYDTianma4.8"240×128
    TM24064BBCWVBYDTianma5.2"240×64
    TM12864G3CIWGNA1-1Tianma2.4"128×64

    We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk


    TM101JDHP01 Specification

    Panel Brand :TIANMA
    Panel Model :TM101JDHP01
    Panel Type :a-Si TFT-LCD , LCM
    Panel Size :10.1 inch
    Resolution :1280(RGB)×800 , WXGA
    Display Mode :SFT, Normally Black, Transmissive
    Active Area :216.96×135.6 mm
    Outline :229.46×149.1×4.3 mm
    Surface :Hard coating
    Brightness :400 cd/m² (Typ.)
    Contrast Ratio :800:1 (Typ.)
    Display Colors :16.7M (8-bit) , CIE1931 50%
    Response Time :10/15 (Typ.)(Tr/Td)
    Viewing Angle :85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :3S11P WLED Without Driver
    Signal Interface :LVDS (1 ch, 8-bit) , 40 pins
    Input Voltage :3.3/11.0/23/-7.0V (Typ.)(VDD/AVDD/VGH/VGL)

    Panel Size :10.1 inch
    Dot Resolution :1280(RGB)×800 (WXGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :149 PPI
    Aspect Ratio :16:10 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0565×0.1695 mm (H×V)
    Pixel Pitch :0.1695×0.1695 mm (H×V)
    Weight :180g (Typ.)
    Surface :Hard coating
    Active Area :216.96×135.6 mm (H×V)
    Outline Dimension :229.46×149.1 mm (H×V)
    Outline Depth :2.5/4.31 (Typ./Max.) mm
    Touch Panel :Without

    TM101JDHP01 Picture
