Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm from wholesalers

    Buy cheap Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm from wholesalers
    • Buy cheap Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm from wholesalers

    Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : TCG070WVLQEPNN-AN20
    Certification : ISO9001
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 2-3 Working Days after order confirmation
    • Product Details
    • Company Profile

    Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm

    Antiglare TCG070WVLQEPNN-AN20 Kyocera LCD Panel 7.0 inch with 152.4×91.44 mm


    TCG070WVLQEPNN-AN20 Specification

    Panel Brand :Kyocera
    Panel Model :TCG070WVLQEPNN-AN20
    Panel Type :a-Si TFT-LCD , LCM
    Panel Size :7.0 inch
    Resolution :800(RGB)×480 , WVGA
    Display Mode :AWV, Normally Black, Transmissive
    Active Area :152.4×91.44 mm
    Outline :165×104.4×9.1 mm
    Surface :Antiglare
    Brightness :350 cd/m² (Typ.)
    Contrast Ratio :650:1 (Typ.)
    Display Colors :262K/16.2M (6-bit / 6-bit + FRC)
    Response Time :18/12 (Typ.)(Tr/Td)
    Viewing Angle :85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :WLED Embedded (LED Driver)
    Signal Interface :LVDS (1 ch, 6/8-bit) , 30 pins
    Input Voltage :3.3V (Typ.)

    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information: salespm@nselectronic.com.hk

    Panel ModelBrandSizeResolution
    F-55472GNFQJ-LW-ABNKyocera2.8"128×64
    F-55472GNFQJ-LG-ADNKyocera2.8"128×64
    F-55472GNFQJ-LB-AENKyocera2.8"128×64
    F-55472GNFJ-SLW-AHNKyocera2.8"128×64
    F-55472GNFJ-SLW-AFNKyocera2.8"128×64
    F-55472GNFJ-SLW-AANKyocera2.8"128×64
    F-55472GNBJ-LW-AINKyocera2.8"128×64
    F-55472GNBJ-LW-AGNKyocera2.8"128×64
    F-55472GNBJ-LW-ACNKyocera2.8"128×64
    F-55471GNFJ-SLW-AMNKyocera5.2"240×64

    Our Company Strength in LCD Screen Sourcing:

    1. ISO9001 certificated, Factory Direct Supplied
    2. Competitive Price and Short Lead-time
    3. Professional Team with Rich Experiences in LCD screen international trade communication.
    4. Small MOQ Support & Fast Response to Customers
    5. Long Product Life Time
    6. 1 Year warranty for our LCD screen replacements.

    FAQ

    Q1: How do we place an order?

    A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.

    Q2: How do we make the payment?

    A2: We accept T/T, Western Union, MoneyGram, Paypal.

    Q3: What's the delivery time?

    A3: The delivery time is normally 1-3 working days after payment.

    Q4: How would the goods be shipped?

    A4: We ship via DHL, UPS, TNT and others.


    Panel Size :7.0 inch
    Dot Resolution :800(RGB)×480 (WVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :133 PPI
    Aspect Ratio :15:9 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0635×0.1905 mm (H×V)
    Pixel Pitch :0.1905×0.1905 mm (H×V)
    Weight :205g
    Surface :Antiglare
    Active Area :152.4×91.44 mm (H×V)
    Bezel Area :154.4×93.4 mm (H×V)
    Outline Dimension :165×104.4 mm (H×V)
    Outline Depth :8.6±0.5 mm
    Holes & Brackets :Without
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    TCG070WVLQEPNN-AN20 Picture
