NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS

    Buy cheap NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS from wholesalers

    Buy cheap NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS from wholesalers
    • Buy cheap NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS from wholesalers

    NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS

    Ask Lasest Price
    Brand Name : NEC
    Model Number : NL10276BC16-04D
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram
    Delivery Time : 1-3 Working Days
    Supply Ability : 500PCS/DAY
    • Product Details
    • Company Profile

    NL10276BC16-04D NEC LCD Panel 8.4 inch 1024×768 600:1 262K/16.7M CCFL LVDS

    NL10276BC16-04D NEC LCD Panel 8.4 inchLCM 1024×768 600:1 262K/16.7M CCFL LVDS


    NL10276BC16-04D Information

    Panel Brand :NEC
    Panel Model :NL10276BC16-04D
    Panel Type :a-Si TFT-LCD , LCM
    Panel Size :8.4 inch
    Resolution :1024(RGB)×768 , XGA
    Display Mode :UA-SFT, Normally Black, Transmissive
    Active Area :170.496×127.872 mm
    Contrast Ratio :600:1 (Typ.)
    Display Colors :262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Response Time :13/12 (Typ.)(Tr/Td)
    Viewing Angle :88/88/88/88 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :2 pcs CCFL
    Signal Interface :LVDS (1 ch, 6/8-bit)
    Input Voltage :3.3V (Typ.)

    Our Services

    1. Quick and accurate reply with best service attidue to our business

    2. Pofessional advise

    3. Quick PI confirmation

    4. Close production follow up and production process feedback

    5. Safe package

    6. Get feekback from your side when items arrived,

    7. 24 months warranty for items


    Panel Size :8.4 inch
    Dot Resolution :1024(RGB)×768 (XGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :152 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0555×0.1665 mm (H×V)
    Pixel Pitch :0.1665×0.1665 mm (H×V)
    Active Area :170.496×127.872 mm (H×V)
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    Our Company Strength in LCD Screen Sourcing:

    1. ISO9001 certificated, Factory Direct Supplied

    2. Competitive Price and Short Lead-time

    3 Professional Team with Rich Experiences in LCD screen international trade communication.

    4. Small MOQ Support & Fast Response to Customers

    5. Long Product Life Time

    6. 1 Year warranty for our LCD screen replacements.


    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    ED097OC1E Ink9.7"1200×825
    ED080XC2E Ink8.0"1024×768
    ED080XC1E Ink8.0"1024×768
    ED060SC3E Ink6.0"800×600
    ED050SC1E Ink5.0"800×600
    PD035QX7E Ink3.5"320×240
    PW070DS6E Ink7.0"480×234
    P1924QC1E Ink2.4"240×320
    PM049OX1E Ink4.9"266×600
    V1835HC1H1E Ink3.5"320×480
    PW100XU2E Ink10.0"640×468
    PW090XUDE Ink9.0"640×220

    We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk


    NL10276BC16-04D NEC LCD Panel Picture
