Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline

    Buy cheap Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline from wholesalers

    Buy cheap Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline from wholesalers
    • Buy cheap Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline from wholesalers

    Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline

    Ask Lasest Price
    Brand Name : Tianma
    Model Number : TM065QDHG01
    Certification : ISO9001
    Payment Terms : Western Union, T/T, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    Hard Coating Tianma LCD Displays TM065QDHG01 158×120.04 Mm Outline

    Normally White TM065QDHG01 Tianma 6.5 inch 132.48×99.36 mm Active Area LCD display panel


    Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.


    We can do for you:

    1. Provide excellent LCD screen replacements with competitive price.
    2. Safe, quick and efficient supply chain.
    3. Plenty of stocks. Branded ones include LCD Screen panels for LG, Samsung, Sharp, BOE, Chimei and so on.
    4. Your problems will be replied within 24 hours.

    Why Choose US:

    1. Prompt reply within 12 hours.

    2. Understand inquiry in any language.

    3. Products with top quality.

    4. Very competitive prices.

    5. 6-year experience in industrial LCD Screen replacements.

    6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.

    7. Fabulous after-sale service.


    TM065QDHG01 Information


    Panel ModelTM065QDHG01-00
    Panel BrandTIANMA
    Descritiona-Si TFT-LCD ,6.5 inch, 640×480
    Panel Typea-Si TFT-LCD
    Display ModeTN, Normally White, Transmissive
    Active Area132.48×99.36 mm
    Outline158×120.04 mm
    SurfaceAntireflection
    Contrast Ratio500:1 (Typ.)
    Display Colors262K (6-bit) , CIE1931 50%
    Response Time20 (Typ.)(Tr+Td)
    Viewing Angle70/70/60/70 (Typ.)(CR≥10) (L/R/U/D)
    Frequency60Hz
    Lamp Type6S3P WLED Without Driver
    Signal InterfaceParallel RGB (1 ch, 6-bit) , 31 pins
    Input Voltage3.3/5.0V (Typ.)(VCC)

    TM065QDHG01-00 Mechanical Features


    Dot Resolution640(RGB)×480 (VGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density122 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.069×0.207 mm (H×V)
    Pixel Pitch0.207×0.207 mm (H×V)
    WeightTBD
    SurfaceAntireflection
    Active Area132.48×99.36 mm (H×V)
    Bezel Area135.48×102.36 mm (H×V)
    Outline Dimension158×120.04 mm (H×V)
    Outline Depth7.0 (Typ.) mm
    Holes & BracketsRear mounting holes (4-R1.75)
    Landscape or PortraitLandscape type
    Touch PanelWithout

    Here comes our other LCD panels stock for your easy reference:


    Panel ModelBrandSizeResolution
    TM240160XCFWGRATianma2.2"240×160
    TM128128F6CCWGWC1Tianma1.44"128×128
    TM12864G3CCWGWA-1Tianma2.4"128×64
    TM050XYSP02Tianma5.0"540×960
    TM050JYHN11-00Tianma5.0"720×1280

    Pls contact to us for more stock information: salespm@nselectronic.com.hk
