M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area

    Buy cheap M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area from wholesalers

    Buy cheap M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area from wholesalers
    • Buy cheap M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area from wholesalers

    M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area

    Ask Lasest Price
    Brand Name : Innolux
    Model Number : M170E1-01
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram,
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area

    M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area


    M170E1-01 Specification

    Panel Size :17.0 inch
    Dot Resolution :1280(RGB)×1024 (SXGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :96 PPI
    Aspect Ratio :5:4 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.088×0.264 mm (H×V)
    Pixel Pitch :0.264×0.264 mm (H×V)
    Weight :2.00/2.15Kgs (Typ./Max.)
    Surface :Antiglare (Haze 25%), Hard coating
    Active Area :337.92×270.336 mm (H×V)
    Bezel Area :342.0×274.4 mm (H×V)
    Outline Dimension :404×322.2 mm (H×V)
    Outline Depth :21.0 (Max.) mm
    Holes & Brackets :Face mounting holes (4-Φ3.4) on left, right bezel
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    Display Mode :TN, Normally White, Transmissive
    Brightness :230 cd/m² (Typ.)
    Contrast Ratio :300 : 1 (Typ.) (Transmissive)
    Display Color :16.2M (6-bit + FRC)
    Response Time :15/35 (Typ.)(Tr/Td)
    Viewing Angle :60/60/40/60 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White Variation :1.25/1.40 (Typ./Max.)(5 points)
    Sunlight Readable :

    N


    Amount per Box :5 pcs
    Box Size :534×316×462 mm (L×W×H)
    Box Gross Weight :8.0 Kgs


    Competitive Advantage:
    1. Rich experience.
    Having been specialized in this field for years, we have rich experience and widespread sales network around the word.

    2. Great quality and high purity
    Good quality is one secret for our success.

    3. Safest and fastest delivery.
    We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
    4. Good after-sales service.


    1. Q: Where can I get the price?

    A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.

    2. Q: How can I get a sample to check your quality?

    A: After price confirmation, you can require for samples to check our quality.

    3. Q: What about the lead time for mass production?

    A: It depends on your order quantity and the season you place the order.

    4. Q: What are your terms of payment?

    A: We accept T/T, Western Union, MoneyGram, PayPal.


    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    P079ZCZ-3Z2Innolux7.9"768×1024
    M315DJJ-Q01Innolux31.5"3840×2160
    V320BJ6-Q01Innolux31.5"1366×768
    V650DK2-QS2Innolux65"3840×2160
    F055A15-6T1Innolux5.5"720×1280
    F050A19-601Innolux5.5"720×1280
    HE101IA-01RInnolux10.1"1280×800
    F055A13-6T1Innolux5.5"720×1280
    F050A13-604Innolux5.0"720×1280
    V650DK6-QS1Innolux65"3840×2160
    M238HCJ-P03Innolux23.8"1920×1080
    V400HJ6-PE1 Rev.C2Innolux40"1920×1080
    V850DK1-QS1 Rev.C4Innolux85"3840×2160
    V850DK1-QS1 Rev.C8Innolux85"3840×2160
    V850DK1-QS1 Rev.C2Innolux85"3840×2160
    V650DJ4-QS5 Rev.M1Innolux65"3840×2160
