15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768

    Buy cheap 15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768 from wholesalers

    Buy cheap 15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768 from wholesalers
    • Buy cheap 15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768 from wholesalers

    15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768

    Ask Lasest Price
    Brand Name : Innolux
    Model Number : M156B1-L01
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768

    15.6 inch M156B1-L01 Innolux LCM 1366×768 250 500:1 16.7M 1366(RGB)×768


    Our advantages in the LCD Screen market:
    1.Better price
    2.Fast delivery
    3.Top quality
    4.First class after - sales service
    5.No memory effect
    6.Sourcing lines & Distributors for the EOL LCD.

    M156B1-L01 Information


    Panel Size :15.6 inch
    Dot Resolution :1366(RGB)×768 (WXGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :100 PPI
    Aspect Ratio :16:9 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.084×0.252 mm (H×V)
    Pixel Pitch :0.252×0.252 mm (H×V)
    Weight :1.30Kgs (Max.)
    Surface :Antiglare (Haze 25%), Hard coating (3H)
    Active Area :344.232×193.536 mm (H×V)
    Bezel Area :347.5×196.8 mm (H×V)
    Outline Dimension :363.8×215.9 mm (H×V)
    Outline Depth :14.3±0.5 mm
    Holes & Brackets :Side mounting holes (4-M3) on left, right bezel
    Landscape or Portrait :Landscape type
    Touch Panel :Without
    Display Mode :TN, Normally White, Transmissive
    Brightness :250 cd/m² (Typ.)
    Contrast Ratio :500 : 1 (Typ.) (Transmissive)
    Display Color :16.7M (6-bit + Hi-FRC)
    Color Gamut :65% NTSC (CIE1931)
    Response Time :2/6 (Typ.)(Tr/Td)
    Viewing Angle :45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.313; Wy:0.329
    White Variation :1.40/1.50 (Typ./Max.)(13 points)
    Sunlight Readable :N
    Amount per Box :10 pcs
    Box Size :490×325×330 mm (L×W×H)
    Box Gross Weight :15.3 Kgs

    Why do you choose us?

    • Quick response to clients' enquiries within 24hrs.

    • More than 6-year experience in LCD screen field and professional team communication team.

    •Value quality and long-term cooperation to reach win-win relationship.


    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information: salespm@nselectronic.com.hk

    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    M238HCJ-P02Innolux23.8"1920×1080
    ME270NA-01AInnolux27.0"1920×1080
    N156BGE-PB1Innolux15.6"1366×768
    PP050IC-01FInnolux5.0"720×1280
    P060DDZ-ZZ1Innolux6.0"800×1280
    ME236NA-01AInnolux23.6"1920×1080
    F055A07-601Innolux5.5"720×1280
    F050A07-6T2Innolux5.0"720×1280
    V650HP1-PS6 Rev.C6Innolux65"1920×1080
    P101LCA-3P1Innolux10.1"1920×1200
    V650HP2-PS5Innolux65"1920×1080
    N156HGE-DB1Innolux15.6"1920×1080

    We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
