Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm

    Buy cheap Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm from wholesalers

    Buy cheap Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm from wholesalers
    • Buy cheap Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm from wholesalers

    Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm

    Ask Lasest Price
    Brand Name : TIANMA
    Model Number : TM022GBH01
    Certification : ISO9001
    Payment Terms : T/T, Paypal, Western Union, MoneyGram
    Supply Ability : 100 PCS / DAY
    Delivery Time : 2-3 working days after payment confirmation
    • Product Details
    • Company Profile

    Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm

    Clear TM022GBH01 Tianma LCD Displays 2.2 inch with 34.848×43.56 mm

    Products Information:

    Panel Size :2.2 inch
    Dot Resolution :176(RGB)×220 (QCIF+)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :128 PPI
    Aspect Ratio :4:5 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.066×0.198 mm (H×V)
    Pixel Pitch :0.198×0.198 mm (H×V)
    Weight :25.0g (Typ.)
    Surface :Clear, Hard coating (3H)
    Active Area :34.848×43.56 mm (H×V)
    Outline Dimension :41.7×56.16 mm (H×V)
    Outline Depth :3.60 (Typ.) mm
    Landscape or Portrait :Portrait type
    Touch Panel :Embeded (4-wire Resistive)


    Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
    We can do for you:

    1. Provide excellent LCD screen replacements with competitive price.
    2. Safe, quick and efficient supply chain.
    3. Plenty of stocks. Branded ones include LCD Screen panels for LG, Samsung, Sharp, BOE, Chimei and so on.
    4. Your problems will be replied within 24 hours.
    Display Mode :TN, Normally White, Transmissive
    Brightness :250 cd/m² (Typ.)
    Contrast Ratio :350 : 1 (Typ.) (Transmissive)
    Display Color :65K/262K ()
    Color Gamut :60% NTSC (CIE1931)
    Response Time :25 (Typ.)(Tr+Td)
    Viewing Angle :45/45/40/20 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.310; Wy:0.330
    White Variation :1.25/1.33 (Typ./Max.)(9 points)
    Sunlight Readable :N


    Here comes our other LCD panels stock for your easy reference:
    Pls contact to us for more stock information: salespm@nselectronic.com.hk

    Panel ModelBrandSizeResolution
    TM050XYS01Tianma5.0"272×480
    TM035PYS01Tianma3.5"320×480
    TM032HYH01Tianma3.2"240×320
    TL060JYXP02Tianma9.0"720×1280
    TL055VYXP02Tianma5.5"1080×1920
    TM024HYH01Tianma2.4"240×320
    TS022GAADY02Tianma2.2"176×220
    TM057JYHP03Tianma5.7"720×1280


    Packaging & Shipping for Our LCD panel
    1. We will ship the LCD display panels within 1-3 workdays after receipt of payment.
    2. We can ship to you by UPS/FEDEX/DHL and so some other direct international express line.
    Other shipping terms can also be arranged according to specific requirements.

    TM022GBH01 Picture
