    Normally White M220J1-L01 Innolux LCD Panel 22.0 inch with 473.76×296.1 mm Active Area

    Ask Lasest Price
    Brand Name : Innolux
    Model Number : M220J1-L01
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram
    Delivery Time : 1-3 Working Days
    Supply Ability : 500PCS/DAY
    • Product Details
    • Company Profile

    Normally White M220J1-L01 Innolux LCD Panel 22.0 inch with 473.76×296.1 mm Active Area

    Normally White M220J1-L01 Innolux LCD Panel 22.0 inch with 473.76×296.1 mm Active Area


    M220J1-L01 Innolux LCD Panel Specification

    Panel Brand :CMO
    Panel Model :M220J1-L01
    Panel Type :a-Si TFT-LCD , LCM
    Panel Size :22.0 inch
    Resolution :1920(RGB)×1200 , WUXGA
    Display Mode :TN, Normally White, Transmissive
    Active Area :473.76×296.1 mm
    Outline :493.7×320.1 mm
    Surface :Antiglare (Haze 25%), Hard coating (3H)
    Brightness :300 cd/m² (Typ.)
    Contrast Ratio :1000:1 (Typ.)
    Display Colors :16.7M (6-bit + Hi-FRC)
    Response Time :1.3/3.7 (Typ.)(Tr/Td)
    Viewing Angle :85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :4 pcs CCFL Without Driver
    Signal Interface :LVDS (2 ch, 8-bit) , 30 pins
    Input Voltage :5.0V (Typ.)

    Here comes our other LCD panels stock for your easy reference:

    Pls contact to us for more stock information: salespm@nselectronic.com.hk

    Panel ModelBrandSizeResolution
    P079ZCZ-3Z2Innolux7.9"768×1024
    M315DJJ-Q01Innolux31.5"3840×2160
    V320BJ6-Q01Innolux31.5"1366×768
    V650DK2-QS2Innolux65"3840×2160
    F055A15-6T1Innolux5.5"720×1280
    F050A19-601Innolux5.5"720×1280
    HE101IA-01RInnolux10.1"1280×800
    F055A13-6T1Innolux5.5"720×1280
    F050A13-604Innolux5.0"720×1280
    V650DK6-QS1Innolux65"3840×2160
    M238HCJ-P03Innolux23.8"1920×1080
    V400HJ6-PE1 Rev.C2Innolux40"1920×1080

    Quality Control:

    1. Visual Inspection

    Make sure No damage, No Scratches, No dusty, No light leakage.

    1. Function Inspection

    Make sure all functions are 100% tested ok


    Packaging & Delivery

    · Delivery Lead Time :2~3 weeks

    · Minimum Order :1 pcs LCD Panel

    · Supply Ability :100 PCS / Per Day


    Panel Size :22.0 inch
    Dot Resolution :1920(RGB)×1200 (WUXGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :102 PPI
    Aspect Ratio :16:10 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.08225×0.24675 mm (H×V)
    Pixel Pitch :0.24675×0.24675 mm (H×V)
    Weight :2.55Kgs (Max.)
    Surface :Antiglare (Haze 25%), Hard coating (3H)
    Active Area :473.76×296.1 mm (H×V)
    Bezel Area :477.7×300.1 mm (H×V)
    Outline Dimension :493.7×320.1 mm (H×V)
    Outline Depth :16.5±0.5 mm
    Holes & Brackets :Side mounting holes
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    M220J1-L01 Innolux LCD Panel Picture
