EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm from wholesalers

    Buy cheap EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm from wholesalers
    • Buy cheap EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm from wholesalers
    • Buy cheap EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm from wholesalers

    EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm

    Ask Lasest Price
    Brand Name : Lumineq
    Model Number : EL320.240.36 HB
    Certification : ISO9001
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 2-3 Working Days after order confirmation
    • Product Details
    • Company Profile

    EL320.240.36 HB Lumineq Optrex LCD Display Panel 5.7 inch with 115.1×86.3 mm

    EL320.240.36 HB Lumineq LCD Panel 5.7 inch with 115.1×86.3 mm for Industrial Application


    What is our advantage?

    Factory Experience: More than 6 years of experience in the agency & sourcing line of Hard-to-find LCD Screen replacements.

    Delivery Quantity: 50-100 cartons shipped by DHL every week

    Supply Ability: 100 pcs Panels per day.

    Supply Area: All over the word (Most of North America, South America, Europe, Japan, Korea and more.)

    Warranty: 12 months.


    FAQ

    Q1: What's price?

    A1: We provide reasonable price and recommend suitable batteries to our customers.

    Q2: What's delivery time?

    A2: The delivery time is normally 1-3 working days after payment.

    Q3: What's the payment?

    A3: We accept T/T, Western Union, MoneyGram, Paypal

    Q4: Can we visit your factory?

    A4: Warmly welcome. Once we have your schedule, we will arrange

    professional sales team to follow up your case.


    EL320.240.36 HB Specification

    Panel Brand :Lumineq
    Panel Model :EL320.240.36 HB
    Panel Type :EL , EL
    Panel Size :5.7 inch
    Resolution :320×240 , QVGA
    Active Area :115.1×86.3 mm
    Outline :148.1×104.7 mm
    Surface :
    Brightness :150 cd/m² (Typ.)
    Contrast Ratio :90 : 1 (Typ.)
    Display Colors :Mono(Yellow) (1-bit)
    Viewing Angle :89/89/89/89 (Typ.) (L/R/U/D)
    Frequency :120Hz
    Signal Interface :Parallel Data (1ch, 4-bit) , 26 pins
    Input Voltage :5/12V (Typ.)(VL/VH)

    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    EL160.80.50 LC CCLumineq3.5"160×80
    EL320.240.36 LKLumineq5.7"320×240
    ELT160.80.50Lumineq3.5"160×80
    ELT256.120.90Lumineq10.0"256×120
    EL160.120.39 CCLumineq3.1"160×120
    EL160.120.39Lumineq3.1"160×120
    EL160.80.50 ET CCLumineq3.5"160×80
    EL160.80.50 ETLumineq3.5"160×80
    EL160.80.50 INLumineq3.5"160×80

    We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk


    Panel Size :5.7 inch
    Dot Resolution :320×240 (QVGA)
    Pixel Configuration :Rectangle
    Pixel Density :70 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.36×0.36 mm (H×V)
    Pixel Pitch :0.36×0.36 mm (H×V)
    Weight :183g
    Active Area :115.1×86.3 mm (H×V)
    Outline Dimension :148.1×104.7 mm (H×V)
    Outline Depth :20 mm
    Holes & Brackets :Face mounting holes (3-Φ3.2, 2-R1.6×4.2)
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    EL320.240.36 HB Picture
