155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap 155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch from wholesalers

    Buy cheap 155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch from wholesalers
    • Buy cheap 155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch from wholesalers

    155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch

    Ask Lasest Price
    Brand Name : Tianma LCD Displays
    Model Number : TM062RDS01
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 100 PCS PER DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch


    155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch


    TIANMA TM062RDS01 General Features

    Panel Brand :TIANMA
    Panel Model :TM062RDS01
    Panel Type :a-Si TFT-LCD , Panel
    Panel Size :6.2 inch
    Resolution :800(RGB)×480 , WVGA
    Display Mode :TN, Normally White, Transmissive
    Active Area :137.4×77.28 mm
    Outline :155.2×88.2×5.2 mm
    Surface :Antiglare
    Brightness :400 cd/m² (Typ.)
    Contrast Ratio :500:1 (Typ.)
    Display Colors :262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 50%
    Response Time :20 (Typ.)(Tr+Td)
    Viewing Angle :75/75/60/70 (Typ.)(CR≥10) (L/R/U/D)
    Frequency :60Hz
    Lamp Type :3S8P WLED
    Signal Interface :Parallel RGB (1 ch, 6/8-bit) , 60 pins
    Input Voltage :3.3/10.5/20.0/-7V (Typ.)(VCC/AVDD/VGH/VGL)

    TIANMA TM062RDS01 Optical Features

    Display Mode :TN, Normally White, Transmissive
    Brightness :400 cd/m² (Typ.)
    Contrast Ratio :500 : 1 (Typ.) (Transmissive)
    Display Color :262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Color Gamut :50% NTSC (CIE1931)
    Response Time :20 (Typ.)(Tr+Td)
    Viewing Angle :75/75/60/70 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :12 o'clock
    White color Chromaticity :Wx:0.306; Wy:0.323
    White Variation :1.25/1.33 (Typ./Max.)(9 points)

    Below are our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    TM240160XCFWGRATianma2.2"240×160
    TM128128F6CCWGWC1Tianma1.44"128×128
    TM12864G3CCWGWA-1Tianma2.4"128×64
    TM050XYSP02Tianma5.0"540×960
    TM050JYHN11-00Tianma5.0"720×1280
    TM055JYSP08Tianma5.5"720×1280

    We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk


    FAQ

    Q1: What's price?

    A1: We provide reasonable price and recommend suitable batteries to our customers.

    Q2: What's delivery time?

    A2: The delivery time is normally 1-3 working days after payment.

    Q3: What's the payment?

    A3: We accept T/T, Western Union, MoneyGram, Paypal

    Q4: Can we visit your factory?

    A4: Warmly welcome. Once we have your schedule, we will arrange professional sales team to follow up your case.


    Packing & Delivery for our LCD Screen Panel Replacements:
    1. Anti-static Bag Packing.
    2. Anti-Shock Bubble Bag Packing
    3. Foam and Hard Carton Packing
    4. Picked up by forward and delivered by express services.


    Quality 155.2×88.2×5.2 mm Outline industrial grade touch screen monitor TM062RDS01 6.2 inch for sale
